LAMINAR AIRFLOW CABINET - MODULAR

1. Characteristics of laminar airflow cabinet - modular form:

The laminar airflow cabinet in its modular form is characterized by a system comprising numerous small modules, each including a housing system (container) and a HEPA filter (H14) manufactured in Vietnam.

2. Features of laminar airflow cabinet - modular form:

In terms of features, it generates a unidirectional airflow from top to bottom, thereby creating positive pressure within the operating room. Additionally, it is designed to accommodate the installation of an operating light cluster.

3. Technical specifications:

The technical specifications of this modular laminar airflow cabinet are as follows:

• It produces a straight laminar airflow.
• The airspeed ranges from 0.25 to 0.3 m/s, adhering to the EN ISO14644 standard.
• The leakage rate is less than 0.01%, meeting the EN ISO 14644-3 standard.
• Equipped with an H14 level terminal Hepa filter according to EN1822.
• The entire system is fitted with pre-installed welding and sealing modules at the factory to ensure cleanliness and tightness in compliance with EN ISO 14644 standards.
• Both the interior and exterior of the module are coated with RAL9010 epoxy paint.
• The system can be easily and swiftly installed using kits featuring rotating clamps and an automatic clamping system.
• It has a long lifespan and maintains a low pressure difference.

For further information and special offers, please contact our company promptly!
